CUSTOMIZABLE SOLUTIONS FOR REFLECTANCE MEASUREMENT APPLICATIONS
Reflectance testing for advanced display technologies, architectural or automotive glass, near-eye displays (AR/VR/MR), and heads-up displays.
At the core of our modular reflectance measurement system is Gamma Scientific’s Gonioreflectometer Head, which uniquely isolates and separates reflection from the first and second surface samples into two beams. Our state-of-the-art spectrometers and Gamma Scientific’s Anti Reflectance Measurement software capture thin film coatings’ complete spectral and colorimetric properties, with rapid scan times typically under one second. Our product range features industry-leading accuracy, repeatability, and throughput, including both refractive index determination and thin film coating thickness.
Our reflectance measurement solutions can be customized to include benchtop transmission, semi-automatic gonioreflectance, and fully automatic measurement systems. We offer on-site installation and training support.
![](https://gamma-sci.com/wp-content/uploads/2024/03/191F_full-300x300.jpg)
REFLECTANCE MEASUREMENT HEADS
The models are available in fixed angle of incidence configurations ranging from 10° to 75°. A handheld unit with a variable angle of incidence is also available. They are capable of first surface or total specular reflection on glass, plastic, metal, or polished substrates and can be used with sample sizes as thin as 400µm. The spectral range is from 380 to 940nm.
![](https://gamma-sci.com/wp-content/uploads/2024/03/GS-191-FA-1045_full-300x300.jpg)
ROTARY REFLECTANCE MEASUREMENT SYSTEM
This fully automatic gonio-reflectance measurement system captures complete spectral and colorimetric properties simultaneously at 0° and 45° angle of incidence for coated glass, polished substrates, or diffuse surfaces without requiring second-surface masking. Substrates as thin as 400 µm can be tested with typical scan times of 300 msec per measurement point.
![](https://gamma-sci.com/wp-content/uploads/2024/03/GS-191-SA-1045_full-300x300.jpg)
SEMI-AUTO REFLECTANCE MEASUREMENT SYSTEM
This semi-automatic reflectance measurement system captures complete spectral and colorimetric properties at 0° to 75° angle of incidence simultaneously for coated glass, polished substrates, or diffuse surfaces without requiring second-surface masking. Substrates as thin as 400 µm can be tested with typical scan times of 300ms per point scan.
![glass wall of a modern business office building in city in blue light and blurred background, business concept](https://gamma-sci.com/wp-content/uploads/elementor/thumbs/AdobeStock_714082668-1-scaled-qo9kx8tga69qod0g4bsk4ukudhm3p1aivx1tdl46n4.jpeg)
![Automobile special workers replacing windscreen or windshield of a car in auto service station garage. Background](https://gamma-sci.com/wp-content/uploads/elementor/thumbs/AdobeStock_210571790-scaled-qo9kxk3ik6p6jok2ago2yrqdi42i9ejaxgvn4wngkg.jpeg)
![Autopilot self-driving car system with no human intervention. Close up cropped image of hand of African male driver browsing the internet using smartphone and touchscreen in futuristic autonomous car.](https://gamma-sci.com/wp-content/uploads/elementor/thumbs/AdobeStock_368201493-scaled-qo9kz3jzret3kobiamn2jvqkjuh5vjngt3dag8d8dc.jpeg)
![Eye care, choice with glasses or contact lens in hands, closeup and vision with healthcare for eyes. Prescription lenses, person with frame and plastic container, optometry with optician and health](https://gamma-sci.com/wp-content/uploads/elementor/thumbs/AdobeStock_712440552-scaled-qo9kzb2pa33e5k0l2pw33tu9axg3l4hbi4l6ag22zk.jpeg)
Test Applications for:
- Anti-Reflectance Coatings
- Architectural Glass
- Automotive Glass
- Eyewear Glass AR Coating
- Pyrolytic Glass Coating
- Display Technologies (2D, 3D Curved, Augmented Reality, Virtual Reality, Heads Up Displays, Near Eye Displays, Advanced Display Technologies, Flat-panel display glass testing, and Touchscreen display glass testing.)
- Optical filter/lens testing
- Characterization of flat panel displays, photovoltaic coatings, low-E architectural coatings, paint samples, and diffuse plastics
Related REsources
Gamma Scientific’s reflectance measurement solutions have been trusted by the leading glass coating and display manufacturers for over 50 years. Learn how we can tailor a reflectance measurement solution to your application.
